Newtec CELOX optical sorting machine

Newtec CELOX optical sorting line

Machine has been upgraded to the newer type CELOX in 2016

The order is based on the following specifications

Ambient temperature ± 5 – 25 ºC.

Product Clean, washed carrots

Capacity: 8 to 10 tons per hour, depending on the batch

(quality and sorting)

Product foreign materials The Celox cannot detect foreign materials such as glass,

wood, stones etc.

Functionality:

Length: +/- 3mm (less than 1% errors)

Diameter: +/- 1mm (less than 1% errors)

broken: 60-65% is removed (on "normal" broken carrots) there will be 5-6% good

carrots among the errors

C/S shape: 85-90% is removed. There will be 3-4% good carrots among the errors

Volume: +/- 5%

-Incl. conversion of complete camera unit to new version

-9 Cameras with 8 megapixel resolution (current 2 magapixel)

Cameras look at the carrots from above and below at an angle

-Better detection of root rot

-Better software for deformed products

-Better software for quality and dimensions

-Incl. set of vibrating channels for the new belts
